Modes:
B-Mode, B/M-Mode
Color Doppler (COLOR), Pulsed Wave Doppler (PW)
8-segment TGC, Split-Screen Display
Up to 1000 seconds Cine Loop
Functions:
Measurement, Annotation, Biopsy
Specialist Mode: 7 Preset Specialties + 6 Custom Modes
DICOM Support, Local Image Export, Reporting
Physical Specs:
Dimensions: 350 × 70 × 28 mm
Weight: 305 g
Battery Life: Up to 2 hours
Imaging Performance
Convex Probe: 3.5–5 MHz, Depth: 90–305 mm, FOV: 60°
Transvaginal Probe: 6–8 MHz, Depth: 30–120 mm, FOV: 149°
128-Element Transducer
256-Level Gray Scale
